Agent Harness

Connect Hosted GroundX MCP Tools

This page is for connecting your AI agent (or your own app) to GroundX’s hosted tools, so it can do GroundX work for you. It covers the address to connect to, how to sign in, which tools you get, and how to reach the more advanced ones.

GroundX supports the Model Context Protocol (MCP), a standard way for AI agents and other clients to call GroundX through a set of ready-made tools. Connecting these hosted tools is optional; you can also work with GroundX entirely from your own code through the Direct SDK/API Quickstart. Whether the hosted tools fit depends on: whether your client supports remote MCP or connectors, whether the connection is available, and whether the tool you need is one of the ones GroundX makes available. See SDK/REST Fallback for the full breakdown.

Setup

Endpoint

On Claude Code and Codex, GroundX Agent Harness registers this server for you. Configuring it again attaches the same server twice.

Configure your MCP client to connect to the GroundX MCP endpoint:

https://api.groundx.ai/mcp

The same server is also reachable at the equivalent path:

https://api.groundx.ai/api/v1/mcp

Either URL works. Use whichever form your client’s configuration expects.

For authenticated GroundX operations, connect to the product endpoint https://api.groundx.ai/mcp (this page).

Authentication

GroundX MCP supports two auth paths:

  • OAuth: for interactive clients that can open a browser (for example Claude Desktop or Codex Desktop). The client discovers OAuth metadata, redirects to a GroundX-hosted authorization page, and receives short-lived MCP tokens. You never handle a raw key in this flow after the initial authorization.
  • X-API-Key transport: for headless or non-interactive clients (for example Claude Code CLI, Codex CLI, Cursor, Replit, or CI runners). The key is sent as an X-API-Key HTTP header on the MCP transport connection:
{
  "mcpServers": {
    "groundx": {
      "url": "https://api.groundx.ai/mcp",
      "headers": {
        "X-API-Key": "${GROUNDX_API_KEY}"
      }
    }
  }
}

Never place a raw API key inside a tool argument. The key belongs only in the transport-layer header or the OAuth flow, never in call_operation, search_content, or any other tool call payload.

Available Tools

Default Tools

A regular customer key sees the 12 default tools below. Which are visible in a given session depends on the scopes granted to the connecting API key (see Scope and Visibility below), so a higher-scope key (for example a Partner-tier key) may register additional tools beyond this set.

ToolMethodPathDerived scope
document_ingestremotePOST/v1/ingest/documents/remotegroundx:ingest
document_getprocessingstatusbyidGET/v1/ingest/{processId}groundx:ingest
document_listGET/v1/ingest/documentsgroundx:ingest
document_getGET/v1/ingest/document/{documentId}groundx:ingest
search_contentPOST/v1/search/{id}groundx:write
search_documentsPOST/v1/search/documentsgroundx:write
bucket_createPOST/v1/bucketgroundx:write
bucket_listGET/v1/bucketgroundx:read
group_createPOST/v1/groupgroundx:write
group_listGET/v1/groupgroundx:read
group_addbucketPOST/v1/group/{groupId}/bucket/{bucketId}groundx:write
health_getGET/v1/health/{service}groundx:read

Always call these tools using the normalized lowercase name shown in the left column (for example document_ingestremote), never a PascalCase operationId form.

Always-Present Tools

In addition to the 12 default tools, 4 tools are always registered regardless of the session’s granted scopes:

  • groundx_account_context
  • list_operations
  • describe_operation
  • call_operation

list_operations, describe_operation, and call_operation are the 3 discovery meta-tools that make advanced operations reachable. groundx_account_context takes no input and returns the resolved account type, mode, granted scopes, base URL, and enabled tool groups for the current session.

Local-File Upload Tool

document_uploadlocal requires the groundx:ingest scope — the same scope document_ingestremote requires, since a session that can’t call document_ingestremote to do anything with an uploaded file shouldn’t be able to get an upload target for one either. It isn’t one of the 12 default tools above and isn’t reachable through call_operation. It takes fileName and fileType, and returns a pre-signed upload target: the URL to PUT the file bytes to, the HTTP method, a header map, and the hosted URL to submit to document_ingestremote.

This only works for MCP hosts that can read the local file and perform the HTTP PUT themselves — not every MCP client can. A host limited to tool-calling alone can’t complete this flow, whether or not the tool exists.

header entries fall into three buckets:

  • Host — the S3 upload host; HTTP clients normally set this automatically from url, so no action is usually needed.
  • GX-HOSTED-URL (if present) — the same value as hostedUrl, riding along in header for convenience. It’s the value to use as sourceUrl later — not a header to send to S3.
  • Any other entries — send them as request headers on the PUT.

See Local Files below for the full flow.

Scope And Visibility

Which tools you see depends on your key’s permissions. The rule that decides this, operationAllowedByScopes(path, method), applied both when filtering visible default tools and inside call_operation before dispatch:

  1. If the path contains /ingest → the required scope is groundx:ingest.
  2. Otherwise, if the method is a write verb (POST, PUT, PATCH, or DELETE) → the required scope is groundx:write.
  3. Otherwise → the required scope is groundx:read.

Both search tools (search_content, search_documents) use POST, so they require groundx:write, not groundx:read. This is intentional.

A session granted only groundx:read sees a reduced set of the 12 default tools, only the tools whose derived scope is groundx:read:

  • bucket_list
  • group_list
  • health_get

All ingest-scoped and write-scoped default tools, including both search tools, are hidden in a read-only session. The 4 always-present tools (the 3 discovery meta-tools plus groundx_account_context) are present regardless of scope, but call_operation still enforces operationAllowedByScopes before dispatch — a read-only session can’t execute write or ingest operations through it either. document_uploadlocal is a separate, fifth tool that is not always-present: it requires groundx:ingest, as noted above.

The visible tools always follow the connecting key’s scopes: a narrower key sees fewer of the 12 default tools, and a higher-scope key (such as a Partner-tier key) registers additional tools beyond them.

Advanced Operations

Operations outside the default 12 (including bucket deletion, document deletion, workflow management, and API key management) aren’t registered as named MCP tools. Reach them through the three always-present discovery meta-tools, in order:

  1. list_operations({}): returns every operation exposed through MCP discovery, each with its operationId, method, path, summary, and description.
  2. describe_operation({ "operationId": "<id>" }): returns the full parameter schema (parameters[] and inputSchema) for one operation, so you can build a valid args object.
  3. call_operation({ "operationId": "<id>", "args": { ... } }): executes the operation and returns the proxied GroundX API result.
call_operation({
  "operationId": "Bucket_delete",
  "args": { "bucketId": 12345 }
})

The argument name is operationId in both describe_operation and call_operation, never operation_id. This is a common mistake; the underscored form doesn’t work.

Scope enforcement still applies inside call_operation, using the same rule described above. A session with only groundx:read gets a scope error if it attempts a write- or ingest-scoped operation this way; discovery doesn’t bypass scope checks. A few operations are further restricted regardless of scope: managing existing API keys (listing, updating, or deleting) requires groundx:admin, and creating a new API key isn’t available through MCP at all; it’s hidden from list_operations and rejected by call_operation for every scope.

Usage Notes

Ingest And Search Workflow

The default tools above cover the standard bucket-create, ingest, poll, and search sequence for answering questions from your own documents. For a full walkthrough of building an agent-driven workflow that answers questions from your documents on top of GroundX’s hosted tools, see Use GroundX With Your Agent.

Local Files

This works only if your MCP host can read the local file and perform the HTTP PUT itself — not every MCP client can. If your host is limited to tool-calling with no such capability, this path isn’t reachable for it — fall back to the direct SDK/API instead (below).

Call document_uploadlocal({ "fileName": "...", "fileType": "..." }) to get a pre-signed upload target, PUT the file’s bytes to the returned url (sending the header entries that need it — see Local-File Upload Tool above for which ones), then call document_ingestremote with the returned hostedUrl as sourceUrl. This matches how the Python SDK’s client.ingest() handles local files internally.

document_uploadlocal({ "fileName": "invoice", "fileType": "pdf" })
// → {
//     "url": "https://eyelevel-upload.s3.us-west-2.amazonaws.com/...",
//     "method": "PUT",
//     "header": {
//       "Host": ["eyelevel-upload.s3.us-west-2.amazonaws.com"],
//       "Gx-Hosted-Url": ["https://upload.eyelevel.ai/prod/file/ssp/....pdf"]
//     },
//     "hostedUrl": "https://upload.eyelevel.ai/prod/file/ssp/....pdf"
//   }

If you’re integrating from application code rather than an MCP client, the GroundX SDKs handle this pre-signed upload flow automatically. See GroundX SDKs and the in-depth ingest guide for the direct-SDK equivalent.
